In stockPhotoelectric Duct Smoke Detector
System Sensor · D2

Photoelectric Duct Smoke Detector

$ 283.72per unit · ex. VAT
The System Sensor D2 is a two-wire photoelectric duct smoke detector designed for HVAC system monitoring. It operates on 12/24 VDC with a maximum current draw of 130mA and supports air velocities from 100 to 4,000 ft/min. The detector features an adjustable housing and tool-free sampling tubes for easy installation and maintenance.
Wiring
2-wire
Current
130mA max.
Voltage
12/24 VDC
Air Velocity
100-4,000 ft./min
Operating Temperature
–4° to 158°F (–20° to 70°C)
Wiring2-wire
Current130mA max.
Voltage12/24 VDC
Air Velocity100-4,000 ft./min
Operating Temperature–4° to 158°F (–20° to 70°C)
Depth2.5"
