The RIDGID 1224 stationary pipe threading machine is in our catalogue — a 1.5 HP, two-speed unit for threading pipe from 1/4" to 4" NPT, with hammer chuck and self-priming oil system.

ChatMRO can make mistakes, so double check it

In stockRidgid Model 1224 Threading Machine with Hammer Chuck, 26092, 1/4 - 4 NPT, 120 V 1224
RIDGID · 1224

Threading Machine with 1/4" to 4" NPT Capacity, 120 V, 1 1/2 hp

$ 15111.59per unit · ex. VAT
The RIDGID 1224 Threading Machine is a stationary power threading machine designed for use with RIDGID Universal Stands. It features a 1 1/2 hp induction motor, self-contained through-the-head oil system, and supports pipe threading from 1/4" to 4" NPT. The machine operates at two speeds (12 and 36 RPM) and is CSA certified for safety.
Capacity
Pipe 1/4" to 4", Rod 1/4" to 2"
Voltage
120 V
Horsepower
1 1/2 hp
Motor Type
Induction
No Load Speed
12/36 RPM
CapacityPipe 1/4" to 4", Rod 1/4" to 2"
Voltage120 V
Horsepower1 1/2 hp
Motor TypeInduction
No Load Speed12/36 RPM
Number of Speeds2
Mount TypeStand
ReversibleYes
Die Head Sizes1/4 inch to 2 inch, 2 1/2 inch to 4 inch
Thread Standard of Included DiesNPT
Pump TypeSelf-Priming Constant Flow Gerotor
Chuck TypeHammer Type with Replaceable Rocker-Action Jaw Inserts
