The Parker H2C is in our catalogue: Material Steel, Body Size 1/4, Thread Size 1/4-18 NPTF.

ChatMRO can make mistakes, so double check it

In stockPneumatic Quick Connect Nipple, 1/4-18 NPTF Thread, Steel
Parker · H2C

Pneumatic Quick Connect Nipple, 1/4-18 NPTF Thread, Steel

$ 5.16per unit · ex. VAT
Non-valved straight-through pneumatic nipple compatible with 20 Series, 30 Series, HF Series, Universal, and E-z-mate couplers. Constructed of steel with trivalent chrome finish, designed for industrial pneumatic applications. Features 1/4-18 NPTF male pipe thread and 1/4 inch body size for standard interchangeability.
Material
Steel
Body Size
1/4
Thread Size
1/4-18 NPTF
Length
1.66
Wrench Flats
0.56
MaterialSteel
Body Size1/4
Thread Size1/4-18 NPTF
Wrench Flats0.56
Exposed Length0.89
FinishTrivalent Chrome
Maximum Pressure300 psi
Temperature Range-40 to 250 degree Fahrenheit
Maximum Flow25 cfm
ApplicationPneumatic
Connection TypeNPT
Interchange TypeIndustrial
