The Parker 20 HP5ON-SS is in our catalogue: Fitting Material Stainless Steel, Material Grade Grade 316, Seal Material NBR Elastomeric Seals as Standard.

ChatMRO can make mistakes, so double check it

In stockHollow Hex Plug with SAE ORB Male Connection, 1-1/4 Inch Pipe Size
Parker · 20 HP5ON-SS

Hollow Hex Plug with SAE ORB Male Connection, 1-1/4 Inch Pipe Size

$ 209.04per unit · ex. VAT
Stainless steel hollow hex plug with SAE ORB male connection, designed for hydraulic fluid applications. Features NBR (nitrile) elastomeric seals as standard, 3/4 inch hex size, and 3/4 inch overall length. Rated for a maximum operating pressure of 4,000 psi and compliant with ISO 6149 standards.
Fitting Material
Stainless Steel
Material Grade
Grade 316
Seal Material
NBR Elastomeric Seals as Standard
Includes Seal
Yes
Includes Pre Applied Thread Sealant
No
Fitting MaterialStainless Steel
Material GradeGrade 316
Seal MaterialNBR Elastomeric Seals as Standard
Includes SealYes
Includes Pre Applied Thread SealantNo
Fitting Side A TypeSAE ORB
Fitting Side A GenderMale
Fitting Side A Nominal Pipe Size1-1/4 Inch
Hex Size3/4 Inch
ApplicationHydraulic Fluid
Max Operating Pressure4,000 psi
Standard LogoISO 6149
