In stockABSOLUTE Digimatic Depth Gage 0-24 Inch with SPC Output
Mitutoyo · 571-215-10

ABSOLUTE Digimatic Depth Gage 0-24 Inch with SPC Output

$ 1150.78per unit · ex. VAT
High-precision digital depth gage with ABSOLUTE electrostatic capacity sensor technology. Features a measurement range of 0-24 inch (0-600 mm), resolution of 0.0005 inch (0.01 mm), and IP67 rating for dust and coolant resistance. Includes SPC data output and automatic power on/off functionality.
Range
0 - 24 inch
Resolution
0.0005 inch / 0.01 mm
Base Width × Thickness
9.8 × 0.39 inch
Battery Life
Approx. 3 years
Power Source
SR44 battery (1 pc.), 938882 included as standard
Range0 - 24 inch
Resolution0.0005 inch / 0.01 mm
Base Width × Thickness9.8 × 0.39 inch
Battery LifeApprox. 3 years
Power SourceSR44 battery (1 pc.), 938882 included as standard
Response SpeedUnlimited
Compatibility NoteCannot be used with U-WAVE-TC
Position Detection MethodElectrostatic Capacity Absolute Sensor
Maximum Permissible Error±0.002 inch / ±0.05 mm
Long Form Calibration CertificateNo
IP RatingIP67
FunctionsAutomatic Power On/Off, In./mm Conversion
