The Mitutoyo 500-506-10 ABSOLUTE Digimatic Caliper is in our catalogue — a 0-24 in / 0-600 mm caliper with electrostatic absolute positioning, SPC output, and stainless steel jaws.

ChatMRO can make mistakes, so double check it

In stockABSOLUTE Digimatic Caliper 0-24 Inch / 0-600 mm with SPC Output
Mitutoyo · 500-506-10

ABSOLUTE Digimatic Caliper 0-24 Inch / 0-600 mm with SPC Output

$ 1136.12per unit · ex. VAT
The Mitutoyo ABSOLUTE Digimatic Caliper features an electrostatic linear encoder for absolute positioning, eliminating the need for zero resetting upon power-on. It offers a measurement range of 0-24 inch / 0-600 mm with a resolution of 0.0005 inch / 0.01 mm and includes SPC data output for quality control integration. The caliper is constructed with stainless steel for durability and includes a plastic case.
Range
0 - 24 inch / 0 - 600 mm
Resolution
0.0005 inch / 0.01 mm
Accuracy
±0.002 inch / ±0.05 mm
Repeatability
0.0005 inch / 0.01 mm
Display
LCD
Range0 - 24 inch / 0 - 600 mm
Resolution0.0005 inch / 0.01 mm
Accuracy±0.002 inch / ±0.05 mm
Repeatability0.0005 inch / 0.01 mm
DisplayLCD
Scale TypeABSOLUTE electrostatic linear encoder
BatterySR44 (1 pc.), 938882
Battery LifeApprox. 3.5 years under normal use
Max Response SpeedUnlimited
AlarmLow voltage, Counting value composition error
FunctionsOrigin-set, Zero-setting, Data output, inch/mm conversion
MaterialStainless Steel
