Hubbell Wiring Device-Kellems hbl2810ar
The Hubbell HBL2810AR is in our catalogue: Poles 4, Wires 5, Voltage 3 Ø Y 120/208.
In stock
Hubbell · HBL2810AR
Safety-Shroud Twist-Lock Angled Receptacle, 30A, 3Ø Y 120/208V, 4P 5W, L21-30R
$ 123.66per unit · ex. VAT
Gray, angled, Safety-Shroud Twist-Lock receptacle with 4 poles and 5 wires, rated for 30A, 3-phase, 120/208V AC. Designed for indoor industrial use with IP20 suitability, grounding, and shrouded configuration to prevent inadvertent contact. Constructed with Valox housing and brass contacts.
Poles
4
Wires
5
Voltage
3 Ø Y 120/208
Amperage
30
Application Type
Type 1 (indoor use)
Poles4
Wires5
Voltage3 Ø Y 120/208
Amperage30
Application TypeType 1 (indoor use)
Conductor MaterialCopper
Housing Screw Torque10 lb-in (1.2 N-m)
Terminal Screw Torque18 lb-in (2.0 N-m)
Conductor Insulation Temperature Rating90ºC or higher
Wire Stripping Length Green Conductor7/16 inch (11 mm)
Wire Stripping Length Other Conductors11/16 inch (17 mm)
NEMA NoL21-30R
Color CodeBLUE
Retainer MaterialPOLYCARBONATE
Angle Cover FinishGRAY
Angle Cover MaterialVALOX 357
Mounting Plate FinishGALVANIZED
Connector Body MaterialNYLON
Mounting Plate MaterialSTEEL
Contact Springs MaterialBRASS
Receptacle Housing FinishGRAY
Receptacle Housing MaterialVALOX 357
GroundingGrounding
Horsepower3 HP
NEMA RatingL21-30R
SuitabilityIP20 SUITABILITY
CertificationsUL, CSA, Fed. Spec.
ContactsBrass
ListingsListed to UL 498, Fed.Spec. W-C-596, Certified to CSA C22.2 No.42
Device ColorGray
FlammabilityV2 or better per UL94/CSA 22.2 No.0.17
Mounting PlateSteel, zinc plated
Housing / FlangeGray RPT
Terminal RetainerClear polycarbonate
Dielectric VoltageWithstands 2,000V minimum
Body Holding ScrewsSteel, zinc plated
Moisture ResistanceIP20 Suitability
Body Contact CarrierNatural (white) nylon
Current InterruptingCertified for current interrupting at full rated current
Operating TemperaturesMaximum Continuous 75 degree Celsius; Minimum -40 degree Celsius (w/o impact)
Terminal Accommodation#16 AWG - #8 AWG solid or stranded copper wire only.
Terminal IdentificationTerminals identified in accordance with UL 498
Package Quantity1
Mount TypeFlush
Flange TypeFlanged
Flange ShapeRectangular
For LocationIndoor
For EnvironmentDry
Number of Gangs1
Wire Connection TypeScrew Terminals
NEMA Enclosure Rating1
Resistance PropertiesCorrosion Resistant, Impact Resistant
Terminal DesignationsTerminals identified in accordance with UL 498 (X, Y, Z, White, Green)
UL 94 Flammability RatingV-2
Maximum Operating Temperature75 degree Celsius
Minimum Operating Temperature-40 degree Celsius
NEMA Receptacle ConfigurationL21-30R
