Hubbell Wiring Device-Kellems cs6365c
The Hubbell CS6365C is in our catalogue: Rating 50A 125/250V AC, Cord Diameter Range 0.830 inch to 1.250 inch (21.08 mm to 31.75 mm), Suitability IP20.
In stock
Hubbell · CS6365C
50A 125/250V AC 3-Pole 4-Wire Twist-Lock Plug
$ 172.59per unit · ex. VAT
Industrial-grade 50A 125/250V AC 3-pole, 4-wire twist-lock plug with nylon housing and brass blades. Features IP20 suitability, impact resistance, and thermoplastic polyester interior for heavy-duty applications. Designed for cord-mounted use with screw terminal connections and operating temperatures from -40°C to 75°C.
Rating
50A 125/250V AC
Cord Diameter Range
0.830 inch to 1.250 inch (21.08 mm to 31.75 mm)
Suitability
IP20
Certifications
UL, CSA
Seal Material
Neoprene
Rating50A 125/250V AC
Cord Diameter Range0.830 inch to 1.250 inch (21.08 mm to 31.75 mm)
SuitabilityIP20
CertificationsUL, CSA
Seal MaterialNeoprene
Shell MaterialStainless Steel
Latches MaterialNylon
Retainer MaterialPolyester
Seal Cup MaterialNylon
Cord Grips MaterialPolyester
Grip Screws MaterialStainless Steel
Blade Holder MaterialPolyester
Box Terminal MaterialCopper
Power Blades MaterialBrass
Rear Housing MaterialNylon
Front Housing MaterialNylon
Grounding Contact Spring MaterialCopper Nickel
Terminal Set Screw MaterialStainless Steel
Grounding Contact Rivet MaterialBrass
Housing MaterialNylon
Interior MaterialThermoplastic Polyester
ColorBlack/White
GradeIndustrial
PhaseSingle
Dimensions6.37 inch x 2.56 inch x 2.56 inch
Wire Size#10 AWG to #6 AWG
Operating Temperature-40°C to 75°C
MountingCord Mounted
Connection TypeScrew Terminals
Number of Poles3
Number of Wires4
NEMA ConfigurationNon-NEMA
UL 94 Flammability RatingHB
SeriesInsulgrip
