The Gast DOA-P504-BN oil-less diaphragm compressor/vacuum pump is in our catalogue — 1/8 HP, 220/240 V, 50 Hz, with 60 psi pressure and 25.5 in Hg vacuum capability.

ChatMRO can make mistakes, so double check it

In stockOilless Diaphragm Compressor/Vacuum Pump, 1/8 HP, 220/240 V, 50 Hz
Gast · DOA-P504-BN

Oilless Diaphragm Compressor/Vacuum Pump, 1/8 HP, 220/240 V, 50 Hz

$ 986.64per unit · ex. VAT
Oilless diaphragm compressor/vacuum pump with 1/8 HP motor, operating at 220/240 V and 50 Hz. Delivers a maximum vacuum of 25.5 inch Hg and maximum pressure of 60 psi. Designed for continuous duty with thermal protection and aluminum housing.
Horsepower
1/8 HP
Power
0.09 kW
Voltage
220/240 V
Frequency
50 Hz
Speed
1275 RPM
Horsepower1/8 HP
Power0.09 kW
Voltage220/240 V
Frequency50 Hz
Speed1275 RPM
Maximum Vacuum25.5” Hg
Max Pressure60 psi
Noise Level70 dBA
Flow Rate0.9 CFM
Inlet Size1/4 inch
Outlet Size1/4 inch
Inlet GenderFemale
