The Gast 4AM-NRV-50C flanged air motor is in our catalogue — 1.7 HP, non-reversible, with NEMA 56C mounting, cast iron housing, and integrated muffler. Certified for hazardous environments per ATEX and EN13463-1.

ChatMRO can make mistakes, so double check it

In stockFlanged Air Motor with Muffler, 1.7 HP, 3,000 RPM, Cast Iron Housing
Gast · 4AM-NRV-50C

Flanged Air Motor with Muffler, 1.7 HP, 3,000 RPM, Cast Iron Housing

$ 514.09per unit · ex. VAT
Explosion-proof flanged air motor with 1.7 HP output, 3,000 RPM no-load speed, and 100 psi maximum operating pressure. Features cast iron housing, 5/8 inch keyed steel shaft, and integrated muffler. Certified for hazardous environments per ATEX and EN13463-1 standards.
Horsepower
1.7 HP
Kilowatts
1.25 kW
Maximum Speed
3,000 RPM
Maximum Operating Pressure
100 psi
Maximum Operating Pressure
7.0 bar
Horsepower1.7 HP
Kilowatts1.25 kW
Maximum Speed3,000 RPM
Maximum Operating Pressure100 psi
Maximum Operating Pressure7.0 bar
Sound Level87 dB(A) MAX
EnvironmentHazardous Ambient Combustible Gas and Dust +1 C to +40 C
Normal Ambient Temperature+1 degree Celsius to -120 degree Celsius
Relative Humidity0 percent - 100 percent
IncludesMuffler
RotationCW/CCW
Inlet Size1/4 inch
