The Gast 4AM-NRV-22B is in our catalogue: Max. Speed 3,000 RPM, Power (HP) 1.7, Power (kW) 1.25.

ChatMRO can make mistakes, so double check it

In stockRotary Vane Air Motor with Face Mount and Keyed Shaft
Gast · 4AM-NRV-22B

Rotary Vane Air Motor with Face Mount and Keyed Shaft

$ 441.69per unit · ex. VAT
Reversible rotary vane air motor with face mount and keyed shaft, designed for hazardous environments. Complies with ATEX and EC Directive 94/9/EC standards. Features cast iron housing, 1/4 NPT ports, and operates up to 3,000 RPM at 100 psi. Includes muffler assembly.
Max. Speed
3,000 RPM
Power (HP)
1.7
Power (kW)
1.25
Max. Pressure (PSI)
100
Max. Pressure (bar)
7.0
Max. Speed3,000 RPM
Power (HP)1.7
Power (kW)1.25
Max. Pressure (PSI)100
Max. Pressure (bar)7.0
Sound Level87 dB(A) MAX.
Net Wt. (kg)3.2
Net Wt. (lbs)7
Relative Humidity0 percent - 100 percent
EnvironmentHazardous Ambient Combustible Gas and Dust +1 degree Celsius TO +40 degree Celsius
Normal Ambient+1 degree Celsius - 120 degree Celsius
RotationReversible
