Gast 2067 V103
ChatMRO

The Gast 2067-V103 rotary vane vacuum pump and compressor is in our catalogue — 1.0 HP, 17 CFM free air flow, 28 in Hg max vacuum, with 3/4 in NPT inlet/outlet.

ChatMRO can make mistakes, so double check it

In stockRotary Vane Vacuum Pump and Compressor
Gast · 2067-V103

Rotary Vane Vacuum Pump and Compressor

$ 1593.32per unit · ex. VAT
General-purpose rotary vane vacuum pump and compressor for continuous duty applications. Operates at 1.0 HP with a maximum pressure of 15 psi and maximum vacuum of 28 inch Hg. Designed for clean, dust-free environments with ambient temperatures from 1°C to 40°C and non-condensing humidity from 8% to 100%.
Power
1.0 HP
Power Metric
0.75 kW
Free Air Flow 0
17.00 CFM
Free Air Flow 10
12.50 CFM
Free Air Flow 10 Inch Hg
10.00 inch Hg
Power1.0 HP
Power Metric0.75 kW
Free Air Flow 017.00 CFM
Free Air Flow 1012.50 CFM
Free Air Flow 10 Inch Hg10.00 inch Hg
Free Air Flow 20 Inch Hg1.00 inch Hg
Flow @ 60 Hz17 CFM
Flow @ 50 Hz14 CFM
Max Pressure15 psi
Max Vacuum @ 50 Hz28 inch Hg
Inlet/Outlet NPT3⁄4 inch NPT
RPM 50 Cycle1425
