Bussmann nsd16
ChatMRO

The Eaton NSD16 is in our catalogue: Ampere Rating 16 A, Rated Voltage 550 V AC, I2T Pre-Arcing 120 Amp² Seconds.

ChatMRO can make mistakes, so double check it

In stockIndustrial HRC Fuse, 16A, 550V AC, BS88, gG/gL Class
Eaton · NSD16

Industrial HRC Fuse, 16A, 550V AC, BS88, gG/gL Class

$ 4.60per unit · ex. VAT
Industrial high rupture capacity (HRC) fuse from the NSD series, rated at 16A and 550V AC. Complies with BS88 and IEC 60269-2 standards. Designed for general industrial applications with blade termination and rectangular cartridge body. Features offset blade tags for secure mounting.
Ampere Rating
16 A
Rated Voltage
550 V AC
I2T Pre-Arcing
120 Amp² Seconds
Nom Watts Loss
1.8 W
I2T Total At 415V
470 Amp² Seconds
Ampere Rating16 A
Rated Voltage550 V AC
I2T Pre-Arcing120 Amp² Seconds
Nom Watts Loss1.8 W
I2T Total At 415V470 Amp² Seconds
I2T Total At 550V730 Amp² Seconds
Fuse TypeBS88
ClassgG/gL
Body StyleCartridge Blade
Termination TypeKnife Blade Offset
Mounting StyleHolder
Product Length60 mm
