The Bussmann 170M1315 is in our catalogue: Size 000, Volts 690Vac (IEC), 700Vac (UL), Watts Loss 16 W.

ChatMRO can make mistakes, so double check it

In stockHigh Speed Square Body DIN 43 653 Fuse, 63 A, 690 V AC, Size 000
Bussmann · 170M1315

High Speed Square Body DIN 43 653 Fuse, 63 A, 690 V AC, Size 000

$ 168.92per unit · ex. VAT
This product can be purchased in multiples of 10
Square body DIN 43 653 stud mount high speed fuse rated for 63 A and 690 V AC (IEC) or 700 V AC (UL), designed for semiconductor, DC drives, and power converter applications. Features a -U/80 without indicator design and meets IEC 60269-4 and UL standards.
Size
000
Volts
690Vac (IEC), 700Vac (UL)
Watts Loss
16 W
I2t Pre-Arc
215 A² Sec
Rated Current RMS
63 A
Size000
Volts690Vac (IEC), 700Vac (UL)
Watts Loss16 W
I2t Pre-Arc215 A² Sec
Rated Current RMS63 A
I2t Clearing at 660V1450 A² Sec
Indicator Style-U/80 Without Indicator
Agency InformationCE, Designed and tested to IEC 60269: Part 4, UL Recognized. UL Recognition/CSA Component Acceptance on Size 000.
Mounting StyleStud
ApplicationSemiconductor, DC Common bus, DC drives, power converters/rectifiers
ClassClass gR ; Class aR
ShapeRectangular
