In stockMechanical Rotatable Crimp Tool for #8 AWG to 4/0 AWG Copper and Aluminum
Burndy · MRC840AL

Mechanical Rotatable Crimp Tool for #8 AWG to 4/0 AWG Copper and Aluminum

$ 371.57per unit · ex. VAT
The BURNDY MRC840AL is a mechanical rotatable crimp tool designed for crimping YA-A and YS-A series connectors on stranded copper and aluminum conductors from #8 AWG to 4/0 AWG. It features a rotating die wheel with 9 crimp grooves, over-center cam action, and color-coded dies that emboss the connector for permanent inspection. The tool is constructed with butting steel jaws and includes a comfort grip handle.
Conductor Range
#8 AWG through 4/0 AWG stranded copper and aluminum
Compatible Connectors
YA-A and YS-A series connectors
Die Type
Rotating Die Wheel
Number of Crimp Grooves
9
Length
26 inch
Conductor Range#8 AWG through 4/0 AWG stranded copper and aluminum
Compatible ConnectorsYA-A and YS-A series connectors
Die TypeRotating Die Wheel
Number of Crimp Grooves9
Dimensions26 inch x 8 inch x 1.5 inch
ApplicationCrimping
Application - For Use OnAluminum Terminals and Splices
Trade NameHYTOOL™
MaterialSteel
Handle TypeComfort Grip
AdjustableManual
Adjustment TypeManual
